:: Steel industry ::::::::::::::::::::::::::::::::::: | ::::::::::::::::::::::::::::::::::: |
![]() |
![]() |
Breakout of a steel ladle in the 227th batch | Breakout of a steel ladle in the 56th batch |
:: Ceramics industry ::::::::::::::::::::::::::::::::::: | ::::::::::::::::::::::::::::::::::: |
![]() |
![]() |
Torn-off inner shell in a tunnel furnace | Damage in the flue gas channel of a top-hat kiln |
:: Glass industry ::::::::::::::::::::::::::::::::::: | ::::::::::::::::::::::::::::::::::: |
![]() |
|
Breakout of an electric arc furnace in the manufacture of mineral wool | |
![]() |
![]() |
Breakout of a bottle glass tank furnace in the bottom from below | Identical breakout from above |
![]() |
![]() |
Destroyed bottom of a fibre glass tank furnace | Side wall of a worn-out bottle glass tank furnace after shot down |
![]() |
![]() |
Destroyed bottom of a tube glass tank furnace after a period of operation of 6 years | Underside of a corroded floor panel |
![]() |
![]() |
Breakout at the side wall of a container glass tank furnace after a period of operation of 4 years and 3 months | Breakout at the passage wall of a container glass tank furnace after a period of operation of 14 months |
![]() |
![]() |
Damage and breakout of a fibre glass tank furnace after a period of operation of 2 years and 4 months | Blocked regenerator passes of a container glass tank furnace after the penetration of water |
![]() |
![]() |
Burning out in the arch of a container glass tank furnace | Burning out in the arch of a container glass tank furnace |
:: Lime industry ::::::::::::::::::::::::::::::::::: | ::::::::::::::::::::::::::::::::::: |
![]() |
|
Arch in a circle lime shaft kiln after cooling following a period of operation of 6 months | |
:: Wood processing industry ::::::::::::::::::::::::::::::::::: | ::::::::::::::::::::::::::::::::::: |
![]() |
|
Destroyed muffle of a wood dust/heavy oil heated boiler after a period of operation of 9 months | |
:: Non-ferrous metal industry ::::::::::::::::::::::::::::::::::: | ::::::::::::::::::::::::::::::::::: |
![]() |
![]() |
Destroyed lining of an aluminium melting furnace after a period of operation of 6 weeks | Breakout of a ferrochromium ladle after the 53rd tapping |
![]() |
![]() |
Breakout of an crucible induction furnace in the 15th fusion | Damage to a brass melting crucible after a period of operation of 25 hours |
:: Crematorium ::::::::::::::::::::::::::::::::::: | ::::::::::::::::::::::::::::::::::: |
![]() |
|
Inspection of a crematorium | |
:: Oil refinery ::::::::::::::::::::::::::::::::::: | ::::::::::::::::::::::::::::::::::: |
![]() |
|
Explosion damage in the chimney of an oil refinery | |
:: Waste incineration plant ::::::::::::::::::::::::::::::::::: | ::::::::::::::::::::::::::::::::::: |
![]() |
|
Flaking in the boiler of a waste incineration plant after a period of operation of 9 months | |
![]() |
|
:: Power station catalyst ::::::::::::::::::::::::::::::::::: | ::::::::::::::::::::::::::::::::::: |
![]() |
|
Damage to a power station catalyst after a period of operation of 2 years | |
![]() |
|
:: Concrete ::::::::::::::::::::::::::::::::::: | ::::::::::::::::::::::::::::::::::: |
![]() |
![]() |
Break-out from a concrete paving stone | Discoloration of an anthracite-grey concrete pavement after four years |
![]() |
|
Fissure on the underside of a filigree concrete ceiling | |
:: Enamelled sheet metal ::::::::::::::::::::::::::::::::::: | ::::::::::::::::::::::::::::::::::: |
![]() |
![]() |
Damage to an enamelled steel tank of a bio gas installation after a period of operation of 12 months | Damage to the enamelling of an soak water tank |
![]() |
|
Damage to the enamelling of a sewage plant tank | |
:: Slate ::::::::::::::::::::::::::::::::::: | ::::::::::::::::::::::::::::::::::: |
![]() |
|
Frost damage to a slate roof | |
:: Ceramic façade cladding ::::::::::::::::::::::::::::::::::: | ::::::::::::::::::::::::::::::::::: |
![]() |
|
Damage to a ceramic façade | |
:: Asphalt ::::::::::::::::::::::::::::::::::: | ::::::::::::::::::::::::::::::::::: |
![]() |
|
Asphalt damage in a truck operating yard |
